Parameters

Cu. Ft
[+]
In
Embedment Stone:
Controlled By (in Ft):
Accessories:
Double Stacked
Note: After making an input change you must hit recalculate to update the Field Diagram and Project Results. Save
NOTICE: This calculator works best in when used with Firefox browser. If using Internet Explorer, please be sure to disable Protected Mode. This calculator has shown issues when used in Chrome with AdBlock enabled. If using Chrome, please disable AdBlock.
This calculator is provided for your convenience only and is not meant for final quotation and/or engineering purposes. Please contact Triton for more information.
Hydrocad-banner Need to model out a full system, or need engineering ready calculations? Triton chambers are available for modeling in HydroCAD by clicking on the HydroCAD banner to the left.

Project Results

Underground-chambers
  • 1 Total Cover Over Chambers: 18.00 In
  • 2 Height of Chamber: 36.0 In
  • 3 Embedment Stone Under Chambers: 6.00 In
  • A Volume of Embedment Stone Required: 339 Cu. Yd
  • B Volume of Fill Material Required: 143 Cu. Yd
Total Storage Provided: 10025.9 Cu. Ft
Type of Distribution Chambers: S-29
# of Distribution Chambers Required: 218
# of end caps required: 16
Type of header row chambers required: S-29
# of header row chambers required: 14
Floors: 0
Bins: 0
Dumpsters: 0
Required Bed Size: 3881.81 Sq. Ft
Volume of Embedment Stone Required: 339.59 Cu. Yd
Volume of Fill Material Required: 143.77 Cu. Yd
Volume of Excavation: 718.85 Cu. Yd
Area of Filter Fabric: 552.92 Sq. Yd
# of Chambers long: 32
# of rows: 7
Actual Trench Length: 96.643 Ft
Actual Trench Width: 40.167 Ft

Field Diagram

Diagram Representing your configured system
Wire-diagram

Chamber Type

S-29
Dimensions 59" x 36" x 35" (WxHxL)
1498.6mm x 914.4mm x 889mm
Weight 32 lbs / 14.5 kg
Bare Chamber Storage 29 ft³ / 0.82 m³

Project Results

Underground-chambers
  • 1 Total Cover Over Chambers: 18.00 In
  • 2 Height of Chamber: 36.0 In
  • 3 Embedment Stone Under Chambers: 6.00 In
  • A Volume of Embedment Stone Required: 339 Cu. Yd
  • B Volume of Fill Material Required: 143 Cu. Yd
Total Storage Provided: 10025.9 Cu. Ft
Type of Distribution Chambers: S-29
# of Distribution Chambers Required: 218
# of end caps required: 16
Type of header row chambers required: S-29
# of header row chambers required: 14
Floors: 0
Bins: 0
Dumpsters: 0
Required Bed Size: 3881.81 Sq. Ft
Volume of Embedment Stone Required: 339.59 Cu. Yd
Volume of Fill Material Required: 143.77 Cu. Yd
Volume of Excavation: 718.85 Cu. Yd
Area of Filter Fabric: 552.92 Sq. Yd
# of Chambers long: 32
# of rows: 7
Actual Trench Length: 96.643 Ft
Actual Trench Width: 40.167 Ft
